ET-89 Asset Tracker long standby Portable Locator for Luggage

Specification

size	Size:  145*67*16 mm (10000mah) Size:  145*67*27 mm (20000mah)
Input	DC: DC 5V/2A
Working Temperature	-20~75°C
Humidity	10% to 90%
CPU	EG800G-EU   (for Europe, Middle East, South America, Africa) EC800M-CN (for   China, India, south and east Asia mainly) EG800Q-NA   (for North America mainly) EG800G-LA   (for Latin America)
GPS features	Re-acquisition sensitivity: -160dBm Tracking sensitivity: -162dBm Accuracy of locating: 2~10 meters Accuracy of speed calculation: <0.1m/s Updating rate of locating: 1~5Hz
Lowest consumption	Below 1mA

Frequency bands:

B1/ 3/ 5 /7/ 8/ 20/ 28 (-EU)

B1/ 3/ 5/ 8/ 34/ 38/ 39/ 40/ 41 (-CN)

B2/ 4/ 5/ 12/ 13/ 66 (-NA)

B2/ 3/ 4/ 5/ /7 /8 /28/ 66 (-LA)

*EU: for some regions in Europe, Middle East, South America, Africa, Asia, Australia

*CN: for China, India, south and east Asia mainly

*NA: for North America mainly

*LA: for Latin America mainly

-----------------------------------------------

Main features:

1.    Charging via: 5V DC

2.    Support GPS and Beidou system

3.    Fast and accurate locating

4.    Static drift suppression

5.    Store data automatically when no GPRS communication

6.    Long time standby

7.    Intelligent power saving

8.    Firmware update OTA

Main functions:

l  Basic functions:

      Position query

      Alarm modes

      Geo fence

      Mileage query and correction

      Power saving mode

l  Settings:

      Data upload interval

      Time zone

      SMS & GPRS switch

      Alarm SMS switch

      DNS

      IP & port

      TCP & UDP switch

l  Alarms:

      Vibration alarm

      Geo fence alarm

      Over speed alarm

      Low battery level alarm

l  Power saving mode:

      Sleep by time

      Wake up by shock sensor

l  Checkings:

      Firmware version

      SIM card ICCID

      Device working status

      IMEI

l  Network functions:

      PC web/APP tracking

      Real time tracking

      Alarm record

      History play back

Packaging detail:

Tracking device

Charging cable

User manual

package box

Optional accessories:

Power adapter (5V 2A)
